Denon DN-408X 8 Channel Audio Mixer

329.99 (including VAT @ 23%)

2 In StockDelivery Information

Item in stock at our Distribution Centre

We currently have this item in stock at our Distribution Centre, ready for dispatch.

"Can be delivered to you on" shows the next available date that we will be able to deliver this item to you on, depending on the delivery option you select, and the stock availability of anything else that you add to your shopping basket.

Can be delivered to you on: 8th December 2016
FREE Delivery available.

Add to Basket

1 year warranty and 30 day money back guarantee included

1 year warranty and 30 day money back guarantee included

Once the product is delivered, you have 30 days to decide that you definitely want to keep it. If you decide it is not suitable for any reason, you can return it back to us for replacement or full refund, including standard delivery charges.

All Products are new unless stated, and include a minimum of one year warranty.

Some items are only eligible for money back guarantee if they are returned to us unused and sealed in the original packaging, and in the case of software, unregistered. These items include:

  • Software
  • CDs & DVDs
  • In-ear Monitors
  • Earplugs and Ear Protection
  • Mouthpieces, Reeds etc… for Woodwind and Brass instruments
  • Mouth / Lip Care Products

We are unable to accept returns of any custom made items designed to work together as a unique package, such as computer system built to a customer’s personal specifications. Exceptions may only be possible with prior agreement of the vendor, and may be subject to a cancellation fee.

Product Ref: 66441

  • 5 XLR Inputs with DNA Mic Preamps
  • 100 Studio-Grade DSP Effects
  • 9-Band Graphic EQ for Main and/or Monitor Outputs
  • Colour-Coded Interface and LED Indicators
  • 3-Band EQ and Two Aux Sends Per Channel

Denon DN-408X 8 Channel Audio Mixer

Details

The Denon DN-408X 8 Channel Mixer is equipped with flexible routing options and a multitude of onboard DSP functions, perfectly designed to meet the demands of virtually any environment including public speaking or conferences and performing arts venues. The 60mm faders with dedicated LED meters provide both precise control and visual feedback for accurate, hands-on mixing. Offering incredible performance, rugged high-quality construction and diverse connectivity options, the Denon DN-408X delivers the utmost capability in a compact, 2-bus portable tabletop format.

Product Ref: 66441

View Full Description

Full Description

View Full Description

Analog Compression and Superior Sound Quality

The DN-408X offers high-fidelity sound and extensive DSP tools, all in a single compact package. Each microphone channel features an ultra low-noise DyNamic Audio (DNA) microphone preamp with generous input signal headroom that ensures unprecedented sound quality and a robust audio signal path. The high headroom that these preamps provide results in cleaner mixes, a purer signal path and detailed, articulate audio that easily makes itself heard.

Onboard analog compression on both channels one and two helps to control the dynamics and automatically rectify unpredictable audio level surges, creating a cohesive and well-defined mix. The DN-408X ensures that the full dynamic range of your mix is delivered with impressive crystal-clear clarity.

USB Audio Interface

Recording live performances, theater performances, speaking events and any other live sound event directly onto your computer has never been simpler. The onboard USB connection gives you the ability to upload your mix directly onto a Mac or PC, meaning that additional editing/mixing and post-production is straightforward and intuitive. Additionally, the USB connection is bi-directional which enables sound files stored on your computer to be sent and played through the mixer too.

100 Studio-Grade DSP Effects

Equipped with 100 premium studio-grade effects built-in, the DN-408X provides you with an extensive range of additional creative controls that are perfect for any mixing environment. The effects include room and delays, small and large hall acoustics, plate and spring reverbs, flangers, choruses and more.

Colour-Coded Interface

Designed for live sound environments that are often poorly lit and have restricted visibility, each section of the mixer is colour coded and includes brightly coloured knobs. Blue, green, red, yellow and white pots can be easily identified in low lighting conditions, while LED indicators for output level, peak and phantom power provide you with multiple visual cues that accurately reflect the actual output.

Features

  • Five XLR inputs with low-noise DyNamic Audio (DNA) microphone preamps
  • Dynamic compression on channels 1 and 2
  • 3-band EQ plus two aux sends per channel
  • 60mm faders with mute switch and LED
  • USB audio connectivity with level control
  • 100 studio-grade digital effects
  • Balanced XLR and balanced/unbalanced 1/4'' outputs
  • 9-band graphic EQ for main or monitor outputs
  • Headphone output with independent level control
  • USB jack to power lamps or charge mobile devices

Specifications

  • Power Consumption: 40 Watts
  • Power Connection: Standard IEC
  • Dimensions: 305mm x 346mm x 80mm / 12'' x 13.6'' x 3.1'' (Width x Depth x Height)
  • Weight: 3.5kg / 7.7lbs

Mono Input Channels

  • Microphone Inputs: Electronically Balanced, Discrete Input Configuration
  • Frequency Reponse: 20Hz - 20kHz ±5dB
  • THD+N: Gain Range: 0dB - 45dB
  • SNR: 105dB

Line Inputs

  • Inputs: Electronically Balanced
  • Frequency Response: 20Hz - 20kHz + 0.25dB
  • THD+N: Sensitivity Range: -15dB - 30dB

Impedances

  • Microphone Inputs: 51.1 KΩ
  • Channel Insert Return: 200 KΩ
  • All Other Inputs: >100 KΩ
  • 2-Track Outputs: 10 KΩ
  • All Other Outputs: 20 KΩ

Equalization

  • High-Shelving: ±15dB @ 12kHz
  • Mid-Bell (Mono): ±15dB @ 2.5kHz
  • Low-Shelving: ±15dB @ 80Hz
  • Main EQ: 9 EQ Bands ±15dB
    • 63Hz, 125Hz, 250Hz, 500Hz, 1kHz, 2kHz, 4kHz, 8kHz, 16kHz

DSP

  • A/D & D/A Converters: 24-Bit
  • DSP Resolution: 24-Bit
  • Effects: 10 DSP Effects Families with 10 Variations Per Family
  • Presets: 100
  • Controls:
    • Rotary Encoder Preset Selector
    • DSP Mute Switch
    • Peak LED Indicator

Main Mix

  • Noise (Bus Noise): -102dBr (ref: +4dBu, fader 0dB, channels muted)
    • -91dBr (ref: +4dBu, fader 0dB, all input channels assigned and set to ''unity'' gain)
  • Phantom Power: Mic Pin2/Pin3 and Pin1 47±2V
Your order may be delivered with a plug adapter
If any electrical items in your order are supplied with a United Kingdom plug connection, a suitable plug conversion adapter will be included free of charge.
