Eventide H9 - Secondhand

Full Description

Complete pedalboard in one pedal

The Eventide H9 Harmonizer is a complete pedalboard in one pedal. The H9 Harmonizer provides you with a range of Eventide's iconic reverb, delay, chorus, modulation, pitch-shifting, and distortion effects. It is an all-in-one, portable solution for the professional and working guitar player, allowing you to take just 1 pedal with you to all your gigs. The H9 features some of the top effect algorithms from their TimeFactor, ModFactor, PitchFactor, and Space pedals, as well as an UltraTap delay specifically made for the H9.

Easy to use design

The H9 Hamonizer features a simple, one-knob user interface for easy operation. This allows for easy effect editing and preset browsing/selection. The two onboard switches are used to switch between presets, tap tempo, and bypass with your feet during a live performance. The H9 Harmonizer offers stereo I/O and full MIDI compatibility. While the H9 is fully controllable via its front panel, a free iOS app (H9 Control) can be downloaded to iPhone and iPad for editing, creating, and managing presets. With the app you can purchase new algorithms, create setlists, and edit and manage presets wirelessly via Bluetooth or USB.

Specifications

Analog Input / Output

• Input Impedance: 600K ohms (mono or stereo)
• Output Impedance: 470 ohms
• Recommended Load Impedance: 10K ohms or greater

Connectors:

• Input 1 (mono): 1/4-inch mono phone jack
• Input 2: 1/4-inch mono phone jack
• Output 1 (mono): 1/4-inch mono phone jack
• Output 2: 1/4-inch mono phone jack
• Expression Pedal: 1/4-inch stereo phone jack
• Mini USB: Use 2.0 cables only
• MIDI In: 5-pin DIN (Female)
• MIDI Out/Thru: 5-pin DIN (Female)
• AC Adapter Jack: Power supply included (see below)

Physical:

• Power: 9 VDC
• Dimensions: 133 x 118 x 50mm (HxWxD)

For more information on the Eventide H9, please refer to the PDF above.
