LD Systems MEI 100 G2 Wireless In-Ear Monitor System - Secondhand

Full Description

Go wireless, stay connected

The LA-W1 system gives you the freedom to move and perform without being anchored by onstage monitors or cables. With a wireless range of up to 120 metres, it’s perfect for musicians and speakers working larger stages, venues, or multi-room events. The ultra-low latency transmission keeps your monitoring accurate and in-sync, so you can focus on delivering your best performance without compromise.

Consistent audio, every time

Operating within the 863–865 MHz license-free Channel 70 band, the LA-W1 avoids the interference issues common with Wi-Fi or Bluetooth. This means reliable, drop-out-free audio in bars, churches, conference halls and more. You don’t need a license to use it in the UK or most of Europe either, making it a cost-effective and hassle-free option for regular live use.

Simple setup and controls

The LA-W1 keeps things straightforward. A clear LCD screen on the receiver and intuitive controls make it easy to monitor battery and audio levels quickly. Whether you’re mid-show or in soundcheck, you won’t waste time in menus or struggling to tweak your setup. It’s built to let you concentrate on your sound, not your gear.

Ready for the road

Touring can be tough on equipment, but the LA-W1 is built to cope. Its bodypack and receiver are solidly made and the supplied in-ear monitors feature high-quality braided cables that resist tangles and damage. Whether you're gigging every weekend or running daily events, the LA-W1 is built for the job.

Specifications

• RF Carrier Frequency Range: 470MHz 960MHz.
• Frequency Stability: 0.005 .
• Effective Working Distance (Ideal Environment): ≥120 Meters.
• Audio Compression And Expansion: DSP Digital Audio Compression And Expansion; Audio Sampling Rate: 48KHz.
• Audio Frequency Response: 50Hz 1800Hz ±3dB.
• Dynamic Range: 92dB.
• Signal-To-Noise Ratio (A-Weighted): 105 dB.
• THD: ≤0.8 @ 1KHz.
• Working Temperature Range: -10°C +50°C.

Receiver Specifications

• Channels: 1 (Mono)
• Receiving Bandwidth: 470MHz 960MHz.
• Image Rejection: 45dBm.
• RF Sensitivity: S/N ≥ 45dB When Inputting 10dBu.
• Squelch Adjustment: Built-In Setting Parameters.
• Frequency Synchronization Method: Manual Button Setting Or Infrared Frequency Pairing.
• Display Mode: Dual Digit Digital Light Plus LED Combination Display.
• Headphone Output Power: 80mW @ 16Ω.
• Output Level Adjustment Range: 5 Levels Adjustable, Attenuation Adjustment, Every 3dB Step.
• Power Supply Mode: AA 1.5V x 2 Can Also Support External Power Supply.
• Normal Working Current: 3V 110mA.
• Battery Life: ≥10 Hours.
• Dimensions: 63 mm x 77.5 mm x 19.5 mm
• Net Weight (Without Battery): 66.8g.

Transmitter Specifications

• Channels: 2 (Stereo)
• Carrier Bandwidth: 470MHz 960MHz.
• Oscillation Mode: PLL Frequency Synthesis.
• Transmission Power: 20dBm/100mW.
• Carrier Deviation: 0.005 .
• Harmonic Radiation: -32dBm.
• Modulation Method: FSK.
• Nominal/Maximum Frequency Deviation: ± 65KHz.
• Audio Input Interface: Balanced XLR, 6.35 mm, 3.5 mm TRS, Lotus Seat.
• Input Impedance: 2.2KΩ.
• Net Weight: 860g.
• Dimensions: 210 mm x 175 mm x 43 mm
